User Manual
1. Press the Math button to display the right menu. Select Type as FFT.
2. Push Cursor to display the cursor menu.
3. In the right menu, select Window as Extension.
4. Press the first menu item in the right menu, select Freq&Vamp for Type, two
blue dotted lines displayed along the horizontal direction of the screen, two blue
dotted lines displayed along the vertical direction of the screen. Cursor measure
window at the left bottom of the screen shows the cursor readout.
5. In the right menu, select Line Type as Freq to make the vertical cursors active. If
the Line in the right menu is select as a, turn the M rotary control to move line a
to the right or left. If b is selected, turn the M rotary control to move line b.
6. In the right menu, select Line Type as Vamp to make the horizontal cursors
active. Select Line in the right menu as a or b, turn the M rotary control to move
it.
7. In the right cursor menu, you can select Window as Main to make the cursors
shown in the main window.
How to Use Executive Buttons
Executive Buttons include Autoset, Run/Stop, Copy.
[Autoset] button
It's a very useful and quick way to apply a set of pre-set functions to the incoming
signal, and display the best possible viewing waveform of the signal and also works
out some measurements for user as well.
The details of functions applied to the signal when using Autoset are shown as the
following table:
Adjust to the proper division.
±
Adjust to the proper division
