multicomp pro MP720009 User Manual

User Manual
57
8. Technical Specifications
Unless otherwise specified, the technical specifications applied are for the
oscilloscope only, and Probes attenuation set as 10X. Only if the oscilloscope fulfills
the following two conditions at first, these specification standards can be reached.
 This instrument should run for at least 30 minutes continuously under the
specified operating temperature.
 If change of the operating temperature is up to or exceeds 5℃, do a
"Self-calibration" procedure (see "How to Implement Self-calibration" on P12).
All specification standards can be fulfilled, except one(s) marked with the word
"Typical".
Performance Characteristics
Instruction
Bandwidth
MP720009
20 MHz
MP720010
50 MHz
MP720011
100 MHz
Channel
2 channels
Acquisition
Mode
Normal, Peak detect, Averaging
Sample rate
(real time)
MP720009
100 MS/s
MP720010
500 MS/s
MP720011
1 GS/s
Input
Input coupling
DC, AC , Ground
Input impedance 1 MΩ±2%, in parallel with 20 pF±5 pF
Input coupling
1X
，
10X
，
100X
，
1000X
Max. input voltage
400V (DC+AC, PK - PK)
Channel –channel
isolation
50Hz: 100 : 1
10MHz: 40 : 1
Time delay between
channel(typical)
150ps
Bandwidth limit MP720009
MP720010
Not support
MP720011
20 MHz, full bandwidth
Horizontal
System
Sampling rate range
MP720009
0.5 S/s
～
100 MS/s
MP720010
0.5 S/s
～
500 MS/s
MP720011
0.5 S/s
～
1 GS/s
Interpolation
(Sinx)/x
Max Record length
10K
Scanning speed
(S/div)
MP720009
5 ns/div – 1000 s/div,
step by 1 – 2 - 5
MP720010
MP720011
2 ns/div – 1000 s/div,
step by 1 – 2 - 5
Sampling rate / relay
time accuracy
±100 ppm
Interval(△T) accuracy
Single
：
