User Manual
(DC - 100MHz) ±(1 interval time+100 ppm×reading+0.6
ns);
Average>16：
±(1 interval time +100 ppm×reading+0.4
Vertical Resolution
(A/D)
8 bits (2 channels simultaneously)
～
±2 V (5 mV/div – 100 mV/div)
±50 V (200 mV/div – 5 V/div)
Analog bandwidth
≥10 Hz (at input, AC coupling, -3 dB)
Typical)
DC gain accuracy ±3%
Delta Volts between any two averages of
≥16 waveforms acquired with the same
scope setup and ambient conditions (△V):
△V, △T, △T&△V between cursors,
auto cursor
Automatic Period, Frequency, Mean, PK-
PK, RMS,
Max, Min, Top, Base, Amplitude,
Overshoot, Preshoot, Rise Time, Fall Time,
+Pulse Width, -
Pulse Width, +Duty Cycle,
-Duty Cycle, Delay A→B , Delay A→B ,
Cycle RMS, Cursor RMS, Screen Duty,
Phase, +Pulse Count, -Pulse Count, Rise
Edge Count, Fall Edge Count, Area, and
Waveform Math
＋, －, *, / ,FFT
Lissajous
figure
Phase
±3 degrees
USB 2.0 (USB storage）
