User Manual
36
How to Implement the Auxiliary System Function Setting
●Config
Push the Utility button, select Function in the right menu, select Configure in the left
menu.
The description of Configure Menu is shown as the follows:
●Display
Push the Utility button, select Function in the right menu, select Display in the left
menu.
The description of Display Menu is shown as the follows:
●Adjust
Push the Utility button, select Function in the right menu, select Adjust in the left
menu.
The description of Adjust Menu is shown as the follows:
Function Menu
Setting
Description
Function
Configure
Show the configure menu
KeyLock
Lock all keys. Unlock method: push Trigger
Menu button in trigger control area, then push
Force button, repeat 3 times.
About
Show the version and serial number
Function Menu
Setting
Description
Function
Display
Show the display menu
BackLight 0% - 100%
Turn the M rotary control to adjust the
backlight.
Graticule Select the grid type
Menu Time OFF, 5S – 30S
Turn the M rotary control to set the
disappear time of menu
Function Menu
Description
Self Cal
Carry out the self-calibration procedure.
Default
Call out the factory settings.
ProbeCh.
Check whether probe attenuation is good.
