Installation
Ultima Hooklift 01/2020
5
1. General
These Hooklift Installation Instructions will give the basic information on the installation of the
hooklifts.
1.1 Suitability
These instructions are meant for the following Ultima Hooklifts S, SL, Z and ZL with Base, Flex
or Pro control system.
1.2 Before starting the installation
Make sure that the Ultima Hooklift to be installed has been checked upon arrival for both
transport damage and contents of the delivery including the kit box.
Check that all the parts are available to complete the installation as planned.
Check that the correct tools and proper lifting gear is available and in good condition.
Check the actual weight of the chassis by weighing it.
Check that the axle weight distribution calculation (TrailerWin) for correct positioning on the
chassis and installation drawings are available.
Check that the truck manufacturer’s installation instructions are available.
1.3 General safety instructions for the installation work
Ultima Hooklift may only be installed by qualified and trained personnel.
Ultima Hooklift can be installed only on suitable truck chassis which is designed for hooklift (or
tipper) use and is allowed to carry the maximum load of the hooklift.
We very strongly recommend that the truck is equipped with as stiff as possible stabi-
lizers (sway bars) on all axles. A closed rear cross beam should be fitted as well!
For further information please refer to your local Multilift dealer.
Always use personal protective equipment and other safety means during the installation work
and while testing the hooklift.
Due to continuous development some of the illustration may look different to the one used in
the hooklift.
Cargotec Finland Oy reserves all rights for this manual.
Cargotec Finland Oy
Raisio
2020
