2. Construction of ULTIMA Hooklift
2.1 Main components of steel construction S & SL
Ultima S
1. Hook arm
2. Middle frame
3. Rear frame
4. Sub frame
5. Container body supports
6. Hydraulic locking
7. Tipping lock
8. Rear rollers
9. Tool console
1
2
3
4
5
6
7
8
Ultima SL
1
2
3
4
5
6
7
8
9
