MultiOne 6 Series User Manual

Instruction manual (Translation of the original instructions)
CM150032EN - 16.06.15 - 05 (11.07.18)
13/76
Self-moving Compact wheel loader, articulated frame, equipped with
multipurpose quick coupler, MULTIONE 6 Series
MultiOne SRL
Ref. Part Function
1 Footrest step It allows to get on the machine safely.
2 Pedals They allow to determine the direction and speed.
3 Wheel It allows to change direction during the translation of the machine.
4 ROPS It protects the operator in charge in case of rolling over of the machine.
5 Roof and FOPS structure
It protects the operator in charge from bad weather and from the direct exposure to the
sunbeams, the FOPS structure protects the operator in charge against the object fall.
6 Document compartment It contains the operating manual.
7 Rear reflectors They make more visible the car.
8 Opening engine space compartment
It protects the engine and prevents the operators in charge to get in touch accidentally
with the mobile parts and high parts.
9 Fuel tank cap It allows refuelling.
10 Engine It moves the hydraulic pumps.
11
Coupling for towing hook or
counterweight (option)
It allows to connect to the machine a coupler for light trailers or to install some
counterweight to increase the stability of the machine.
12 Central steering joint Actuated by a hydraulic cylinder allows the steering of the machine.
13 Wheels They support and allow the machine movement.
14 Disconnecting battery key It allows to disconnect the battery.
15 Working lights They provide more visibility in a situation of poor lighting.
16 Control panel
It assembles operating controls of the machine and of the possible attachment assembled
to the machine.
17
Driving seat supplied with armrests and
safety belt
It is for the operator in charge to be seated and fastened to the machine.
18 Hydraulic circuit pipes They allow the passage of the hydraulic oil for assembled equipping working.
19 Lifting arm It raises possible attachment assembled of the machine.
20 Multi - connector It allows the connection to the attachment hydraulic circuit.
21 12 V DC power outlet It provides power to any electrical devices on the assembled attachment.
22 Quick coupler It allows the mechanic connection to attachment.
TAB. 2
DESCRIPTION OF THE MACHINE -4
