MultiOne 6 Series User Manual

MultiOne SRL
Self-moving Compact wheel loader, articulated frame, equipped with
multipurpose quick coupler, MULTIONE 6 Series
Instruction manual (Translation of the original instructions)
CM150032EN - 16.06.15 - 05 (11.07.18)
52/76
8.4.6 Towing the machine on
WARNING
IT IS FORBIDDEN TO TOW THE MACHINE OFF AND/OR LIFT IT BY ANY MEANS OF TRANSPORT.
If the machine remains blocked, it is possible to tow it for a short trip (MAX. 20 mt), only if on, by a suitable towing vehicle.
To make this proceed as follows:
1) Put the machine in “safety state” (see par. 9.2).
2) Connect to the attachment points of the machine (FIG. 31 - Ref. 1) the ropes and/or chains of towing.
3) Turn on the machine (see par. 8.3.2) nd, as far as possible, facilitate towing operations.
1
1 1
FIG. 30
FIG. 31
8- OPERATION

MultiOne 6 Series Specifications

General

Brand	MultiOne
Model	6 Series
Category	Compact Loader
Language	English
