MultiOne 6 Series User Manual

Instruction manual (Translation of the original instructions)
CM150032EN - 16.06.15 - 05 (11.07.18)
17/76
Self-moving Compact wheel loader, articulated frame, equipped with
multipurpose quick coupler, MULTIONE 6 Series
MultiOne SRL
Ref. Name Function
5 Ignition lock key
By Key on and turned to the right carries out respectively:
• Position: “0”: machine off.
• Position “1”: power to control panel.
• Position “2”: pre-heating (glow plug ignition).
• Position “3”: starting the machine.
6 Multifunction device A collection of indicators and warning lights (see par. 4.3.2).
7 Multifunction joystick
It controls the movement of the lifting arm, of the quick coupler and the operation of the possible
assembled attachment (see par. 4.3.3).
8 Throttle
It regulates the engine speed.
• Position “Hare” (forward): it increases engine rpm.
• Position “Turtle” (backward): it lowers engine rpm.
9 Button commands See (see par. 8.2)
10 Radio with Bluethoot Optional.
11
Buzzer (overheating engine
alarm)
It is an acoustic device that is activated when there is an abnormal overheating of the engine.
12 Proportional pedal forward
Pressed downwards (with the right foot): allows the forward movement of the machine and
increases its speed in proportion to the pressure exerted on the same.
13 Proportional pedal backward
Pressed downwards (with the right foot): allows the backward movement of the machine and
increases its speed in proportion to the pressure exerted on the same.
14
Heating temperature
control knob
(option)
It controls the heating temperature.
• Rotated clockwise it increases the temperature.
• Rotated counterclockwise it decreases the temperature.
TAB. 4
DESCRIPTION OF THE MACHINE -4
