Subject: FreshBlender FAQ & Troubleshooting
Motor Shaft Alignment
NOTE: Visit https://www.multiplexbeverage.com/Videos for
video instruction.
Product bag pump may not fully slide over motor shaft causing
pump latch not to clip over pump easily.
NOTE: Never force product bag pump over motor shaft. Forcing
pump over motor shaft could lead to damaging the pump or
the motor shaft.
1. Remove product bag and bin from cabinet.
2. Locate the motor shaft.
3. Place tool on motor shaft and turn.
4. Place bin with correctly installed product bag and pump
into bin slot.
5. Gently slide product bag pump over motor shaft. If pump
does not easily slide over motor shaft, pull bin out and
slightly turn motor shaft again.
6. Snap product pump latch over end of pump..
FIGURE 1 - Remove Product and Bin
FIGURE 2 - Place Tool onto Motor Shaft
FIGURE 3 - Verify New Product Bag Is Installed Correctly
FIGURE 4 - Replace Product and Bin
