Multiplex FreshBlender User Manual

18 Part Number: WBL-95-156 REV002
Operation Section 3
ICE MAKING
Main Power Switch - Front Top Right of the Unit
Power
Switch
The ice machine will not start until:
1. The power ON/OFF switch is in the “ON” position.
2. Ice does not contact the bin level sensor/switch.
3. The water reservoir is full of water.
4. After 15 minute delay when power cycled.
15 Minute time delay
The 15 minute delay must be expired before the gear motor
or compressor will energize.
The delay period starts to time out upon application of
power or movement of the toggle switch from OFF to ICE.
The delay period starts when:
• The ice machine enters Automatic Shutoff
• Power is disconnected and reconnected
• The toggle switch is moved from OFF to ICE
This time delay period can not be overridden and will reset
to 15 minutes if any of the above conditions occur.
PRIOR TO STARTUP
When the toggle switch is placed in the ICE position the following
must occur in the listed order before ice making will start.
• The ice chute damper must be in the closed or down
position.
• The 15 minute delay period must be expired. The delay
period starts upon application of power or toggle switch
movement from OFF to ICE.
• The water sensing switch must be closed (water reservoir
full of water and water sensing float in the up position).
INITIAL STARTUP
Applying power and/or moving the toggle switch from OFF
to ICE will start a 15 minute delay period. This delay period
can not be overridden. With the water sensing switch closed
(reservoir full of water) the gear motor will energize at the end
of the 15 minute time delay. The compressor and condenser
fan motor energize 5 seconds after the gear motor.
FREEZE CYCLE
The float valve automatically maintains the water level in
the reservoir. The ice damper will open and close to verify
ice production. The ice machine will continue to make ice
until the ice damper is held open (up) as ice fills the bin.
AUTOMATIC SHUTOFF
When the ice damper is held open by ice, the gear motor,
compressor and condenser fan de-energize. The fifteen
minute delay period starts to time out. The ice machine will
remain off until the 15 minute delay period expires and the
ice damper closes.
RESTART AFTER AUTOMATIC SHUTOFF
1. Less than 4 hours have passed since automatic shut-off.
With the water sensing switch closed (reservoir full of water)
the gear motor will energize at the end of the 15 minute time
delay. The compressor and condenser fan motor energize 5
seconds after the gear motor.
2. More than 4 hours have passed since automatic shut-off.
The dump valve energizes to drain the evaporator. After 30
seconds the dump valve de-energizes. When the reservoir
fills with water, the water sensing switch closes and the gear
motor energizes. The compressor and condenser fan motor
energize 5 seconds after the gear motor.
NOTE: Ice machines use an auger to remove ice from the
evaporator. Occasional noises (creaks, groans, squeaks, or
pops) are a normal part of the ice making process.
