5.2 Custom table installation
A Cell can be installed as a table in a horizontal or tilted position, or in a custom enclosure.
A Cell is attached to the enclosure by the rear panel corner or handle M8 screw holes.
A simplified custom setup would consist of sturdy supporting legs on each side, firmly wrapping
the Cell and keeping it at the minimum safe distance limited by handles from the top of a stable
surface.
To complete a custom installation, follow these steps:
1. Prepare the custom table or enclosure for the Cell.
2. Ensure that the Cell has sufficient ventilation (cool air in, hot air out). See the diagrams in
section 5.2.2 and section 5.2.3.
3. MultiTaction Air Flow Channels has to been used in the displays on table installations.
4. Locate the M8 type screw holes. Note maximum 14 mm screw depth in the corner M8
mounting holes.
5. Use M8 steel screws with steel grade 12.9 (ref. chapter 5.1).
6. Firmly attach the Cell with 20Nm torque to the custom table or enclosure using M8 screws
and the Cell’s screw holes. Ensure the Cell is correctly aligned.
Warning:
Never install a Cell inside a fully enclosed space! Risk of device overheating, which can lead to
critical hardware failure and personal injuries.
Ensure the custom enclosure design complies with the minimum safe distance between the Cell
underside and the base of the enclosure to allow sufficient air ventilation (cool air in, hot air
out).
Loosely installed Cell may fall and cause personal injuries.
Attach the Cell properly by the M8 screw holes. If the Cell is installed in a public environment,
check the condition of the enclosure and attachments regularly.
Avertissement:
Ne jamais installer la Cellule dans un espace entièrement los! Risque de surchauffe du dispositif
pouvant causer une panne critique du matériel et des blessures corporelles.
S’assurer que les dimensions et le montage du dispositif d’utilisation conforment avec les
distances de sécurité requises, au dessus d’une surface stable, et que la Cellule a son propre
système de ventilation (entrée d’air frais, sortie d’air chaud).
Une Cellule qui n’est pas montée solidement peut tomber et causer des blessures corporelles.
Attacher la Cellule correctement par les trous de vis M8. Si la Cellule est installée dans un
milieu public, contrôler régulièrement la condition du boîtier et des fixations.
