MT CELL SETUP MANUAL MT556XNB, MT556UNB AND MT557D | 30
6 CONNECT THE CELL
Revision 3.0 www.multitaction.com
15.9.2020
P/N: MT2201012
6.4 USB mouse and keyboard
To show the on-screen display (the OSD), you will need a mouse and keyboard attached to USB
ports on the Cell.
For convenience, you may prefer to attach a wireless mouse and keyboard so you can stand in
front of the Cell while using the on-screen display.
However, after the OSD appears on-screen, you can configure it to accept finger input. That is, you
can use your fingers to configure settings in the OSD.
Note: You do not need a mouse or keyboard to use the OSD when the Cell first starts up.
During start-up, the OSD displays automatically and you can configure it to accept finger input.
Remarque: Vous n’avez pas besoin de souris ou de clavier pour utiliser l’OSD au premier
démarrage de la Cellule. Pendant le démarrage, l’OSD s’affiche automatiquement et vous
pouvez le configurer pour accepter la saisie au doigt.
6.5 Connections to the SYNC IN / OUT
In the multiple Cell installations, like display walls, the Cells can be synchronize to have same
camera capture timing to optimize the tracking engine function. Cells are connected in chain with
3.5 mm plug stereo cable from the one display sync out to the other display sync in; see
connectors in section 2.3. This operation is not functional at the moment.
