MT CELL SETUP MANUAL MT556XNB, MT556UNB AND MT557D | 29
6 CONNECT THE CELL
Revision 3.0 www.multitaction.com
15.9.2020
P/N: MT2201012
6.2 Connections to an external application computer
MultiTaction Cells require an external application computer with two cable connections. While the
Cell and application computer are disconnected from the power supply, connect:
Ethernet cable from the Cell to the application computer
An Ethernet cable transmits finger locations and marker information to the application
computer. The cable is generally connected to a switch on the LAN so the Cell can use the
connection to download firmware updates as necessary. Alternatively, you can connect the
Cell directly to the application computer. We do not recommend a wireless connection
because of the latency it introduces.
Video cable from the Cell to video outputs on the application computer
This cable enables the video image from the computer to be displayed on the Cell:
The video cable connects to a DisplayPort video input.
Ensure there is no stress or tension on the connected cables. After connecting all cables, connect
the Cell and computer to the mains supply.
Note: For a description of the Cell connection panel, see section 2.3.
Remarque: Pour une description du panneau de connexion de Cellule, voir la section 2.3.
6.3 Connections to the internet
We recommend that all Cells have an internet connection. For this reason, Cells have an Ethernet
port for connecting to your default gateway or an external computer; see section 2.3.
If you intend to display Web applications on your Cells, your application computer must have an
internet connection.
Note: Network settings for the Cell’s tracking engine are described online, at address:
https://hardware.multitaction.com/
Remarque: Les paramètres du réseau du moteur de suivi de la Cellule sont décrits en ligne, à
l’adresse: https://hardware.multitaction.com/
