multivac C100 - Installation conditions and ambient conditions

Description
Technical specifications
13.05.2014 31
Dimensions
Height (a) with closed chamber
lid
330 mm
Width (b) 400 mm
Depth (c) 500 mm
Operating height approx. 256 mm
Effective chamber size (W/H/D) 310 mm/120 mm/310 mm
Sealing length 305 mm
Weight approx. 50 kg
Fig. 18: Dimensions
Installation conditions and ambient conditions
Ambient temperature +2 °C to +40 °C
Storage temperature -25 °C to +80 °C
Relative air humidity during op-
eration or storage of the ma-
chine, max.
90 % non-condensing
Inclination of the machine during
transport, max.
15 °
Minimum room size for machines
with gas flushing option*
40 m
2
*For safety reasons, a minimum room size is mandatory to prevent
high concentrations of gas.
