5-30 Using the Web Browser
q Registering a new LDAP server
(1) Select a number (01 to 05) that has not been registered.
The “LDAP Server Settings” dialog appears.
(2) Configure the settings and click [Save].
Item Description
Name Enter the name for identification purposes.
Server Name Enter the LDAP server name.
IP Address Enter the IP address of the LDAP server.
• IP address is given to priority if both the LDAP server
name and IP address are registered.
Port Number Enter the port number that the LDAP server is using.
The default port number is 389.
Account Enter the account name used to log-on to the LDAP server.
Password Enter the password used to log-on to the LDAP server.
Login Required If the LDAP server requires authentication, select “Yes”.
User Login If the optional “OfficeBridge Expansion Kit” has been
installed, select “Yes”. Otherwise, select “No”.
Start Point Set the search start position when searching the LDAP
server.
To Next Page
