3-8 Cleaning
Cleaning the scanning area

Cleaning the ADF rollers
If the document feeder rollers are dirty, the documents may become dirty and black lines
may appear in the scanned images. This can also cause a document jam.
Clean the ADF at least once a month to ensure that documents are transmitted with high
image quality.
IMPORTANT
Do not use benzene or thinner as cleaning agents, as they may damage the plastic and
paint of the machine.
1
Open the ADF cover.
2
Use a soft cloth moistened with water and well-wrung to clean the face of the
rollers.
Rotate the rollers by hand to clean the entire roller surface.
3
Open the inner cover.
4
Use a soft cloth moistened with water and well-wrung to clean the face of the
rollers.
Rotate the rollers by hand to clean the entire roller surface.
5
Close the inner cover and ADF cover.
