Appendix A - menu system > 115
Network
Menu (cont.)
LDAP Server
Setting
Server Setting
LDAP Server:
Port No.:
Timeout:
Max. Entries:
Search Root:
user defined
1 ~ 389 ~ 65535
10 ~ 30 ~ 120second(s)
5 - 100 Entries
user defined
Edit the LDAP server
settings.
Attribute
Name1:
Name2:
Name3:
E-mail Address:
Additional Filter:
cn
sn
givenName
mail
user defined
Edit the LDAP search
attribute if required.
Authentication
Method: Anonymous, Simple,
Digest-MD5, Secure
Protocol
Set the authentication
method for LDAP.
User ID: user defined Set a user ID and
password for the LDAP
server.
Displays when
authentication method
is set.
Password: user defined
Encryption None, LDAPS,
STARTTLS
Set the encryption
method.
Secure
Protocol
Server
Setting
Domain user defined Domain must be
registered in the DNS
server.
Management Default Mode Copy, Scan, Print, Fax
Operation
Clear
Operation Timeout After 1 ~3~ 10 minutes
Clear After Job ON, OFF
Sound
Control
Key To u ch Tone
Volume
OFF, Low, Middle, High Select key touch volume
level.
Fax Buzzer Volume OFF, Low, Middle, High Select volume level.
Local
Interface
USB Menu
Soft Reset:
Speed:
USB PS_Protocol:
Offline Receive:
Serial Number:
Enable, Disable
480Mbps, 12 Mbps
ASCII, RAW
Enable, Disable
Enable, Dis
able
Default settings listed,
these can be changed if
required.
System
Setup
Access Control PIN, User/Password,
Disable
Enable access control to
restrict usage to
authorised user only.
Unit Of Measure Inch, Millimeter Select unit of measure.
Date Format mm/dd/yyyy,
dd/mm/yyyy,
yyyy/mm/dd
Select desired date
format.
Allow All Reports To
Print
Enable, Disable Enable/disable report
printing.
ITEM OPTION VALUE/DESCRIPTION
