Tab. 9-26: Description of individual diagnostics - device events
0x4510
(17680)
0x7709
(30473)
0x7709
(30473)
Cable break of the subordinate device 9 Check the installation.
0x4510
(17680)
0x770A
(30474)
0x770A
(30474)
Cable break of the subordinate device 10 Check the installation.
0x4510
(17680)
0x770B
(30475)
0x770B
(30475)
Cable break of the subordinate device 11 Check the installation.
0x4510
(17680)
0x770C
(30476)
0x770C
(30476)
Cable break of the subordinate device 12 Check the installation.
0x4510
(17680)
0x770D
(30477)
0x770D
(30477)
Cable break of the subordinate device 13 Check the installation.
0x4510
(17680)
0x770E
(30478)
0x770E
(30478)
Cable break of the subordinate device 14 Check the installation.
0x4510
(17680)
0x770F
(30479)
0x770F
(30479)
Cable break of the subordinate device 15 Check the installation.
0x4510
(17680)
0x7710
(30480)
0x7710
(30480)
Short Circuit Check the installation.
0x4510
(17680)
0x7711
(30481)
0x7711
(30481)
Grounding error Check the installation.
0x4511
(17681)
0x8000
(32768) –
0xFFFF
(65535)
Event from an IO-Link device that supports
Murrelektronik IO-Link integration.
The Extended Channel Error Type plus
0x8000 (32768) corresponds to the original
IO-Link event code.
0x4511
(17681)
0x0100
(256)
0x8100
(33024)
Communication monitoring: General error Check the device.
0x4511
(17681)
0x0110
(272)
0x8110
(33040)
Process data monitoring: General error Check the device.
0x4511
(17681)
0x0C00
(3072)
0x8C00
(35840)
Technology-specific error in the application Reset the device.
0x4511
(17681)
0x0C01
(3073)
0x8C01
(35841)
Simulation active Check the operating mode.
0x4511
(17681)
0x0C10
(3088)
0x8C10
(35856)
Process value above the valid range Process value uncertain
0x4511
(17681)
0x0C20
(3104)
0x8C20
(35872)
Measuring range exceeded Check your application.
0x4511
(17681)
0x0C30
(3120)
0x8C30
(35888)
Process value below the valid range Process value uncertain
0x4511
(17681)
0x0C40
(3136)
0x8C40
(35904)
Service requirement - cleaning Clean the device.
0x4511
(17681)
0x0C41
(3137)
0x8C41
(35905)
Service requirement - topping up Top up the device.
0x4511
(17681)
0x0C42
(3138)
0x8C42
(35906)
Service requirement - wear Replace the wearing parts on the
device.
0x4511
(17681)
0x0CA0
(3232) –
0x0DFE
(3582)
0x8CA0
(36000) –
0x8DFE
(36350)
Device-specific error code For further details on this IO-Link
event, please read the IO-Link
device manual.
Channel
Error Type
Extended
Channel
Error Type
IO-Link
Event
code(s)
Meaning Action
