Technical Data
User manual 55530_hdb_en_16 32 / 156
Derating
Short circuit protection High-side switch with
overload protection
Connection / female connector M12
Conductor cross-section M12 ≤0.75 mm
2
Output
Fig. 4-3: Derating DO output current Fig. 4-4: Derating actuator supply total current
IO-Link
IO-Link devices operating voltage 24 V
IO-Link devices voltage range 20 ... 30 V
Specification V1.1.2
Transfer rate Com 1/Com 2/Com 3
Transfer rate recognition Automatic
Input characteristic EN 61131-2, type 1
