VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL Before using
3.3 Filling ink 71
6. Rotale Ink cartridge slot by 90 degrees upward.
3.3.1 Changing the angle of Ink cartridge slot (VJ-2638/1638X/1638WX)
7. Insert Cleaning cartridge into Ink cartridge slot.
• Keep the arrow of Cleaning cartridge facing the front side of the printer and insert it into the
printer.
No. Name
1 Ink cartridge slot
No. Name
1 Cleaning cartridge
2 Arrow
1
2
1
