MUTOH VJ-2638 - Page 86

Before using VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL
86 3.4 Loading media
2. Tighten Fixing lever of Roll media holder (Left) and fix the roll media holder (Left).
3. Set the roll media to Roll media holder (Left).
No. Name
1 Roll media holder (Left)
2 Fixing lever
No. Name
1 Roll media holder (Left)
2 Roll media
1
2
1
1 2
