11
MV Heating UK Ltd
Figure V
18. Control Switch/Timer 19. Main Wire Harness
20. Fuel Pump 21. Mounting Gasket
22. Combustion Air Inlet Pipe 23. Exhaust Pipe
24. Fuel Pump Extension Loom 25. Fuel Standpipe
26. Fuel Pipe 27. Fuel Pump Bracket
28. Fuel Filter 29. Exhaust Pipe Clip
30. Exhaust Pipe Fixing Clip 31. Air Inlet Fixing Strap
32. Fuel Connector Hose Clip 33. Fuel Line Connector
34. Air Inlet Hose Clip 35. Control Fixing Screw
36. Anti-Vibration Mount (M6)
Figure V shows the diagram for installation. The position and ways of fixing of
various parts may vary from one vehicle/boat to another, but the general
principles remain the same.
Attention:
• Do not mount the heater near any flammable sources
• Do not install the heater in closed spaces without ventilation
• Do not place the heater near anything that can cause a blockage
• Do not mount the heater near any water sources and protect it from
any splashing
