The direction of the heater for installation is shown in figure IX.
Ensure you do not exceed the inclination angle or normal operation will be
affected.
After installation, make sure there is no friction between the fan and other
nearby parts to ensure smooth operation and make sure the heater label is
clearly visible for ease of maintenance in the future.
Air Inlet & Outlet
Make sure that the hot air outlet does not exit onto any parts affected by
heat and that it isn’t directed toward the flow of anything that can cause a
blockage, near splashing water or near the vehicles exhaust.
Correct Wrong
Figure X
Avoid re-entering of the supplied hot air into the inlet port (as shown in
Figure X). If no inlet pipe is required, make sure the grill is installed at the inlet
port instead (Figure IV no. 17).
