Timer and Rheostat Control Plugs
Use a single screw to fix the timer control or rheostat control in place. They
are best installed so that they can be seen and operated easily to identify
working conditions and for easy access. The black and clear plugs connect to
the corresponding plugs on the loom (below). The remaining three-pin socket
on the timer or rheostat control plugs into the remote-control receiver if one
is installed. An adaptor cable may be necessary.
Timer Control Plug
Figure XXII
Rheostat Control Plug
Figure XXIII
