MV Heating MV Airo 2 - Operation and Controls; Rheostat Control Usage

+44 (0)23 8052 2345
28
MV Heating UK Ltd
Operation
Rheostat Control
1. Variable Output Button and Indictor Light
2. Temperature Button and Indicator Light
3. Fan Only (Cold Air) Button and Indicator Light
4. Control Knob
5. Fixing Screw Hole (Located underneath control knob)
Figure XXVI
The rheostat (or rotary) control works by twisting the control knob to the
desired heat setting, and using the buttons listed to determine the heaters
function. Variable output is simply high to low heat. The temperature button
switches the heater to thermostatic mode (the heater will then switch to a
cool-down cycle automatically once it has reached the selected temperature).
The fan button only switches the fan on for cool air.
°C
1
2
3
5
4
