Introduction
The main equipment of the MV Airo 2 air heater (hereinafter referred to as
‘the heater’) is a small fuel furnace controlled by a single-chip micro-
processor. Its furnace body (the heat exchanger) is located in the hood
shaped case, which serves as an independent air passage. Cold air is drawn
into the air passage by the fan and blown out when it becomes hot.
The heat can be supplied by the heater to the driver’s cab and passenger’s
compartment independently from the engine. The schematic diagram is
shown in Fig I.
The heater is fully automatically controlled. It features a compact structure,
easy installation, low running costs, easy maintenance and is safe and
reliable.
1. Control switch
2. Heater Body
3. Fuel Pump
4. Wiring Harness
5. Vehicle’s Battery
6. Vehicle’s Fuel Tank
7. Exhaust Pipe
8. Combustion Air
Intake
Figure I
1
2
5
6
3 4
8
7
