Circuit Interfaces
The connection parts on the controller case are designed in such a way that
wrong connections are impossible to make.
The following circuit interfaces can be found on the controller case; these are:
• X1: Fan motor
• X2: Glow plug
• X3: Overheat sensor
• X4: Leads to fuel pump
• X5: Unused
• X6: Main Wiring Harness
Figure XXV
X6
X1
X2
X3
X4
X5
