SquareFolder
Open the top cover.
Lift up both upper feed belts (A).
Note
Press the green dots (B) on the latches to release.
Remove the misfeeds.
Place the upper feed belts in normal position.
Close the top cover.
Inside the SquareFolder
Exit area
Open the top cover (A).
Lift up the cover (B) of the Belt stacker.
Remove the misfeeds.
Place the cover in normal position.
Close the top cover.
A
A
Clearing misfeed(s)
SquareFolder
B
B
B
