REMARKS
Maintaining Your Machines
Never attempt any maintenance function that is not specifically described in this
documentation.
Booklet Maker
Oil Clinchers and Stapler heads
Stapling area,
view from infeed
close-up of clincher
lever
close-up of clincher
lever
close-up of
clincher
A
BB
The clinchers must be oiled every 20 000 stapling cycles to avoid mechanical breakdown.
