mycom 220JS-V User Manual

2205B0JE-DA-J-N_2014.05.
7 Related Documents
Screw Compressor J-series 7.1 Development View and Configuration Table of the Parts
7-4
Part
No.
Part name
170J
Type, etc.
Part code No. Quantity/unit
Standard
Explosion
proof for
Propane
S M L
38-2
Thrust bearing assembly, female
rotor
7309BEAXT7DF CS03800-J170F 1
39-1 Locknut AN12 NG31-012 1
39-2 Locknut AN09 NG31-009 1
40-1 Lock washer AW12 NG32-012 1
40-2 Lock washer AW09 NG32-009 1
41-1
Thrust bearing outer race spacer,
male rotor
CS04100-J170M 1
41-2
Thrust bearing outer race spacer,
female rotor
CS04100-J170F 1
42-1
Thrust bearing alignment spacer,
male rotor
CS04200-J170M 1
42-2
Thrust bearing alignment spacer,
female rotor
CS04200-J170F 1
43-1 Thrust bearing gland, male rotor CS04300-J170M 1
43-2 Thrust bearing gland, female rotor CS04300-J170F 1
44-1
Thrust bearing gland spacer, male
rotor
CS04
400-J170M 1
44-2
Thrust bearing gland spacer,
female rotor
CS04400-J170F 1
45 Hexagon head screw M8×30 NB35408-030 12
46 Conical spring washer
Hexagon head
screw M8
ND330-08 12
48 Retainer for oil seal CS04800-J170 1
49 O-ring JIS B 2401 G120 PAH81-120 PC12-120 1
50 Oil seal SA1J 65 85 12 CS05010-200VD 1
51 Seal cover 1
52-1 O-ring JIS B 2401 G120 PAH81-120 PC12-120 1
52-2 O-ring JIS B 2401 G145 PAH81-145 PC12-145 1
53 Hexagon socket head cap screw M8×30 NB35408-030 8
54
Unloader slide valve S 1 — —
Unloader slide valve M — 1 —
Unloader slide valve L — — 1
58 Hexagon socket head cap screw M8×30 NB35408-030 6
60 Unloader cylinder 1
61 Hexagon socket head cap screw M12×70 NB35412-070 2
62 Hexagon socket head cap screw M12×110 NB35412-110 6
63-1 O-ring AS568A-258 PAH82-258 PC62-036 2
63-2 O-ring JIS B2401 P14 PAH80-014 PC11-014 2
64 Unloader piston CS06400-J170 1
65 O-ring JIS B2401 P130 PAH80-130 PC11-130 2
66 Teflon cap seal SUNR-BE-130 CS06600-J170 2
67 Push rod, unloader slide valve CS06700-J170 1
68 Guide pin PH01NG 3×8 BK CS06809-03 1
69 Locknut FU nut FU05SS NG42-05 1
70 Plain washer
Small, product
grade A, 24×39
1
73 O-ring JIS B2401 P32 PAH80-032 PC11-032 1
74 Unloader cylinder cover 1
75-1 O-ring JIS B2401 G135 PAH81-135 PC12-135 1
75-2 O-ring JIS B2401 P14 PAH80-014 PC11-014 1
76 Hexagon socket head cap screw M10×40 NB35410-040 8
77
Unloader indicator cam S CS07700-J170S 1 — —
Unloader indicator cam M CS07700-J170M — 1 —
Unloader indicator cam L CS07700-J170L — — 1
78 Ball bearing #6000 CS07800-200 1
79 Retaining ring C type external JISB2804 (S10) NG12-010 1
80 Bearing gland CS08000-200 1
81 Hexagon socket head cap screw M6×15 NB35406-015 3
82-1 O-ring JIS B2401 P10A PAH80-010A PC11-010A 2
