mycom 220JS-V User Manual

2205B0JE-DA-J-N_2014.05.
7 Related Documents
Screw Compressor J-series 7.1 Development View and Configuration Table of the Parts
7-5
Part
No.
Part name
170J
Type, etc.
Part code No. Quantity/unit
Standard
Explosion
proof for
Propane
S M L
82-2 O-ring JIS B2401 P16 PAH80-016 PC11-016 1
83 Retainer, O-ring CS08300-170J 1
84 Spacer, unloader cylinder cover CS08400-J170 1
91 Shaft key CS09100-J170 1
100
Mechanical seal assembly
(including 100-1 to 100-5)
CS10002-J170 1
100-1 O-ring AS568A-334 PAH82-334 PC61-037 1
100-2 Mating ring 1
100-3 Rotating ring 1
100-4 O-ring AS568A-227 PAH82-227 PC61-005 1
100-5 Hexagon socket set screw M8×9 1
120 Assembly, unloader indicator 1
137 Dial plate, unloader indicator CS13700-J170 1
234 Name plate 1
237-1 Torsional slip washer M CS23700-160 1
237-2 Torsional slip washer F CS23700-125 1
246 Guide, unloader slide valve 1
247 Hexagon socket head cap screw M8×70 NB35408-070 4
248 Spring lock washer
Hexagon socket
head cap screw M8
ND330-08 4
249 Parallel pin 8 dia.×60 NE2008-060 2
250-1 Thrust washer, male rotor CS25000-160 1
250-2 Thrust washer, female rotor CS25000-125 1
267 Spring lock washer
Hexagon socket
head cap screw M8
ND330-08 6
289
Slide valve S, Vi 1 — —
Slide valve M, Vi — 1 —
Slide valve L, Vi — — 1
292
Push rod S, Vi 1 — —
Push rod M, Vi — 1 —
Push rod L, Vi — — 1
293 Spiral retaining ring FRSN-45 NGFR-45 2
294 Piston, Vi CS29400-J170 1
295 O-ring JIS B2401 P52 PAH80-052 PC11-052 1
296 Cylinder, Vi 1
297 Partition plate, unloader cylinder CS29700-J170 1
298 O-ring JIS B2401 G135 PAH81-135 PC12-135 1
299-1 O-ring JIS B2401 G100 PAH81-100 PC12-100 1
299-2 O-ring AS568A-258 PAH82-258 PC62-036 1
325-1 O-ring JIS B2401 P32 PAH80-032 PC11-032 3
325-2 Back-up ring for O-ring SUN-2BP 32 PBP21-032 2
396-1 Liner M for thrust adjustment 160*** (Service part)
396-2 Liner F for thrust adjustment 125*** (Service part)
420
Unloader spacer S CS42000-J170S 1 — —
Unloader spacer M CS42000-J170M — 1 —
421 O-ring JIS B2401 P32 PAH80-032 PC11-032 2 —
432 O-ring JIS B2401 G100 PAH81-100 PC12-100 4
433 O-ring JIS B2401 G75 PAH81-075 PC12-075 4
446 Grooved pin PY01ND 5×10 BK 1
451
Push rod gland for unloader slide
valve
CS45100-J170 1
458-1 Plug R1/2 NF06-015 1
458-2 Plug R1/4 NF06-008 4
459 Plug R3/8 NF06-010 1
481 Check valve slider CS48100-J170 1
485 Spring, check valve
O.D 23, wire
diameter 1.8
Free length 95
CS48500-J170 1
486 Locknut FU nut FU04SS NG42-04 1
