MZ electronic WHC040 - Off Time Setting; Language Selection; Sensor Configuration; Sensor Type Selection

WHC040 Rev. 01-2021
English
25
Off time
This function allows the user to set the
backlight on time during which the display
remains lit after the last command given
(default value 30 seconds).
Select with
Select value with
Confirm with
Language
The user may select the display language:
Italian, English, French, German, Spanish
Select with
Select value with
Confirm with
Exit
To return to the settings menu.
Confirm with
Sensor menu
SENSOR
BARBOTIN 33.0
DIVISOR 1
TEST
EXIT
SENSORE STD
Use the (DOWN) or (UP) key to move around the parameters.
Sensor
This function selects the sensor type:
• 2-wire standard sensor (STD)
• 3-wire electronic sensor (HAL)
Select with
Select value with
Confirm with
Barbotin
The circumference of the gypsy must be
entered in this row (in centimeters or inches).
To enter the correct value see the paragraph
"instrument calibration"
Select with
Select value with
Confirm with
Divisor
If the standard 2-wire electronic sensor
(STD) is used, this value must be left at 1. If
the 3-wire electronic sensor is used, the
divider must be set equal to the number of
gypsy teeth. See paragraph "Instrument
calibration".
Select with
Select value with
Confirm with
