Page 37
5-1 Removing the Header Assy
The fitting position of the Header Assembly is high, and it is important that
a means of reaching the height safely, without stretching, is available. (e.g.
Steps, Step Stool etc.)
1. Remove 6off pozi head screws (3 each side).
2. Lift the header assembly sufficient to reach the connector.
3. Disconnect the connector and remove the Header assembly.
4. Reassemble in reverse order.
Pozi head screw
(M5x12)
Pozi head screw
(M5x12)
Connector
To Next Page
