Page 76

Button head screw

(M5 x 12)

Brake pedal Assy

Accelerator pedal assy

Pedal plate R

Connectors

7-12 Removing the Pedal Assy

1. Remove 4off button head screws (M5x20).

2. Withdraw the pedal assembly only sufficiently to disconnect the connectors.

3 Remove the pedal assembly.

4. Reassemble in reverse order
