NAMCO MARIO KART User Manual

Page 83
7-16 Removing the Sound PC Boards
1. Remove the back door from the Monitor Cabinet.
2. Disconnect the connectors.
3. Disengage the 4off locking supports, and remove the FCA PC Board.
4. Reassemble in reverse order.
Locking support
PC Board
Long-nose
pliers
Click
<To detach>
<To attach>
IS Amp PC Board
Bass Amp PC Board
