Page 41
5-5 Adjusting the Level Adjuster
1. When the game is in it’s final position, lower the twelve (12) Level adjusters (4off
Monitor Cabinet and 4off each Seat Base Assy),with a spanner, so that all
castors are raised from the floor by approximately 5mm. Tighten the lock nuts
with a spanner to ensure that the Level Adjusters do not move.
Note: If the site of this game has a smooth or polished floor, it is recommended that
rubber pads are fitted under the Level Adjusters to prevent the game sliding on
the floor when in use.
Level adjuster
Castor
Approx. 5mm
Lock Nut
