Page 71
PC Board
<to Fit>
<To Remove>
Click
Locking Support
Long-nosed
pliers
Steering PC Board
Connectors
Connectors
7-7 Removing the Steering PC Board
1. Disconnect the six connectors.
2. Using long-nosed pliers, release the locking supports and remove the PC Board.
3. Reassemble in reverse order.
