NAPCO GEMINI GEM-P1664 User Manual

L NAPCO Security Systems
X GEM-P1664 Programming Instructions

Page 21
WI1423A 1/06
KEYPAD ADDRESS PROGRAM MODE DISPLAY
DIRECT ADDRESS PROGRAM MODE KEYPAD COMMANDS
A. GEM-K2AS (and GEM-RP2ASe2) Keypad
GEM-RP2ASe2/GEM-K2AS Keypads
00003C
1 2
= ADDRESS LOCATION
1 2 = DATA ENTRY LOCATION (Left and Right Digits)
Direct Address Program Mode
Press R followed by (1) the 4 digit
address location, and (2) the corresponding
data shown.
(Direct Entry)
3P
INTERIOR
BYPASS FIRE/TBL SYS TBL CHIME
3C
INTERIOR
BYPASS SYS TBL CHIME
FIRE/TBL
1
2
Flashing
GEM-RP3DGTL/GEM-K3DGTL Keypads
To access, press C in
Dealer Program Mode
1. Toggle Cursor to 4-digit ad-
dress field using the
R
button.
2. Enter address Number directly
using number buttons (0-9).
3. Enter Data directly using num-
ber buttons.*
4. Press the
U button to save.
To exit, press C.
NOTE: Press 0 button to clear character at cursor.
Select NEXT/PRIOR Address.
Press GP to jump to next programming block.
* Press
G0 through G5 for 10-15, respectively.
GEMINI
00003C
A
R
M
E
D
COMPUTERIZED SECURITY SYSTEM
S
T
A
T
U
S
R 1 2 3
B 4 5 6
C 7 8 9 0
U
NEXT/YES
P
PRIOR/NO
Q
AREA
G
Press R followed by (1) the 4 digit
address location, and (2) the corresponding
data shown. Note: A long beep sounds
when in Address Program Mode.
1
2
GEM-RP4RFC/GEM-K4RF Keypads
P
3C
