X GEM-P1664 Programming Instructions
L NAPCO Security Systems
Page 26
WI1423A 1/06
[Default = blank (•) blank (•) from address 0836-0843] Note: If Test Timer is enabled (above), Digital Dialer Test is also enabled.
SYSTEM OPTIONS (ADDRESS 0836-0871 & 2045)
1. Select the desired option by circling the data values for each digit (left
and right).
2. Add the data values (ex: F=15=(1+2+4+8) from the selected options. See page 23).
3. Enter in address location (left and right digits). NOTE: Dark shaded data value box shows option not available.
4. Press U or D to save.
GLOBAL AMBUSH CODE: It is the 2-digits entered immediately prior to the regular disarm code.
If “Enable Global Ambush Code” (Address 1422) is selected and Address 2045 is left blank (•), then
the 2-digit Global Ambush Code is “99”. If “Enable Global Ambush Code” is selected and Address
2045 is not left blank (•), then the 2-digit Global Ambush Code is the two digits entered in address
2045.
Enter in address location (both left and right digits) ; valid entries are 1-9.
Press U or D to save.
Direct Address Program Mode
SYSTEM RESPONSE
ACTIVATED BY GLOBAL
GLOBAL SYSTEM EVENT/TROUBLE
LEFT DATA VALUES (CIRCLE )
ADDRESS 0836-0843
EVENT/TROUBLE
Bell
Superv.
EZM
TAMPER
AC FAIL LOW
BATTERY
LEFT ADDR RIGHT
MEMORY
FAILURE
RF RCVR.
TROUBLE
TELCO
FAILURE
TEST
TIMER
Alarm Output 8 4 2 1
0836
8 4 2 1
Pulsed Alarm Output 8 4 2 1
0837
8 4 2 1
PGM1 Output 8 4 2 1
0838
8 4 2 1
PGM2 Output 8 4 2 1
0839
8 4 2 1
Report Event Telco 1 8 4 2 1
0840
8 4 2 1
Report Restore Telco 1 8 4 2 1
0841
8 4 2 1
Report Event Telco 3 8 4 2 1
0842
8 4 2 1
Report Restore Telco 3 8 4 2 1
0843
8 4 2 1
GLOBAL SYSTEM EVENT/TROUBLE
RIGHT DATA VALUES (CIRCLE )
* NOTE: Keypad Aux. is not to be selected for UL Instal-
lations.
[Default = blank (•) blank (•) from address 0856-0863]
SYSTEM RESPONSE
ACTIVATED BY AREA 1
AREA 1 SYSTEM EVENT/TROUBLE
LEFT DATA VALUES (CIRCLE )
ADDRESS 0856-0863
EVENT/TROUBLE
Keyfob
Low Batt.
FAIL TO
CLOSE
FAIL TO
OPEN
KEYPAD
TAMPER
LEFT ADDR RIGHT
KEYPAD
AUX.*
KEYPAD
FIRE
KEYPAD
PANIC
AMBUSH
Pulsed Alarm Output 8 4 2 1
0856
8 4 2 1
Alarm Output 8 4 2 1
0857
8 4 2 1
PGM1 Output 8 4 2 1
0858
8 4 2 1
PGM2 Output 8 4 2 1
0860
8 4 2 1
Report Event Telco 1 8 4 2 1
0861
8 4 2 1
Report Event Telco 3 8 4 2 1
0863
8 4 2 1
AREA 1 SYSTEM EVENT/TROUBLE
RIGHT DATA VALUES (CIRCLE )
* NOTE: Keypad Aux. is not to be selected for UL Instal-
lations.
[Default = blank (•) blank (•) from address 0864-0871]
SYSTEM RESPONSE
ACTIVATED BY AREA 2
AREA 2 SYSTEM EVENT/TROUBLE
LEFT DATA VALUES (CIRCLE )
ADDRESS 0864-0871
EVENT/TROUBLE
Keyfob
Low Batt.
FAIL TO
CLOSE
FAIL TO
OPEN
KEYPAD
TAMPER
LEFT ADDR RIGHT
KEYPAD
AUX. *
KEYPAD
FIRE
KEYPAD
PANIC
AMBUSH
Pulsed Alarm Output 8 4 2 1
0864
8 4 2 1
Alarm Output 8 4 2 1
0865
8 4 2 1
PGM1 Output 8 4 2 1
0866
8 4 2 1
PGM2 Output 8 4 2 1
0868
8 4 2 1
Report Event Telco 1 8 4 2 1
0869
8 4 2 1
Report Event Telco 3 8 4 2 1
0871
8 4 2 1
AREA 2 SYSTEM EVENT/TROUBLE
RIGHT DATA VALUES (CIRCLE
)
[Default = blank (•) blank (•)]
Global
LEFT RIGHT
Ambush Code
ADDRESS 2045
