CS USER REPORTING OPTIONS (ADDRESS 0800-0817)
CS USER REPORTING OPTIONS: [Default = blank (•) blank (•) from address 0800-0817]
1. Select the desired option by circling  the data values for each digit (left and right).
2. Add the data values (ex: F=15=(1+2+4+8) from the selected options. See page 23).
3. Enter in address location (left and right digits). NOTE: Dark shaded data value box shows option not available.
4. Press U or D to save.
Direct Address Program Mode
LEFT DATA VALUE ADDRESS 0800
User Opening
Telco 1
User
8
User
7
User
6
User
5
LEFT RIGHT User
4
User
3
User
2
User
1
8 4 2 1 8 4 2 1
RIGHT DATA VALUES LEFT DATA VALUE ADDRESS 0801
User
16
User
15
User
14
User
13
LEFT RIGHT User
12
User
11
User
10
User
9
8 4 2 1 8 4 2 1
RIGHT DATA VALUES
User 65 = Auto Arming/Disarming
User 66 = Quickloader Remote Arming/Disarming
User 67 = Easy Arming
(Opening not applicable)
User 68 = Keyswitch Arming
NOTE: These opening events will report
as the user number shown. Also, Key-
fobs 1-8 (see Easy Menu Program Driven
Mode) will report as Users 57-64, respec-
tively.
ADDRESS 0808
User Opening
Telco 1
LEFT RIGHT User
68
User
67
User
66
User
65
blank (•)
8 4 2 1
RIGHT DATA VALUES
LEFT DATA VALUE ADDRESS 0806
User Opening
Telco 1
User
56
User
55
User
54
User
53
LEFT RIGHT User
52
User
51
User
50
User
49
8 4 2 1 8 4 2 1
RIGHT DATA VALUES LEFT DATA VALUES ADDRESS 0807
User
64
User
63
User
62
User
61
LEFT RIGHT User
60
User
59
User
58
User
57
8 4 2 1
8 4 2 1
RIGHT DATA VALUES
LEFT DATA VALUE ADDRESS 0802
User Opening
Telco 1
User
24
User
23
User
22
User
21
LEFT RIGHT User
20
User
19
User
18
User
17
8 4 2 1
8 4 2 1
RIGHT DATA VALUES LEFT DATA VALUES ADDRESS 0803
User
32
User
31
User
30
User
29
LEFT RIGHT User
28
User
27
User
26
User
25
8 4 2 1 8 4 2 1
RIGHT DATA VALUES
LEFT DATA VALUES ADDRESS 0804
User Opening
Telco 1
User
40
User
39
User
38
User
37
LEFT RIGHT User
36
User
35
User
34
User
33
8 4 2 1
8 4 2 1
RIGHT DATA VALUES
LEFT DATA VALUE ADDRESS 0805
User
48
User
47
User
46
User
45
LEFT RIGHT User
44
User
43
User
42
User
41
8 4 2 1 8 4 2 1
RIGHT DATA VALUES
LEFT DATA VALUE ADDRESS 0809
User Opening
Telco 1
User
8
User
7
User
6
User
5
LEFT RIGHT User
4
User
3
User
2
User
1
8 4 2 1 8 4 2 1
RIGHT DATA VALUES LEFT DATA VALUE ADDRESS 0810
User
16
User
15
User
14
User
13
LEFT RIGHT User
12
User
11
User
10
User
9
8 4 2 1 8 4 2 1
RIGHT DATA VALUES
User 65 = Auto Arming/Disarming
User 66 = Quickloader Remote Arming/Disarming
User 67 = Easy Arming
(Opening not applicable)
User 68 = Keyswitch Arming
NOTE: These opening events will report
as the user number shown. Also, Key-
fobs 1-8 (see Easy Menu Program Driven
Mode) will report as Users 57-64, respec-
tively.
ADDRESS 0817
User Opening
Telco 1
LEFT RIGHT User
68
User
67
User
66
User
65
blank (•)
8 4 2 1
RIGHT DATA VALUES
LEFT DATA VALUE ADDRESS 0815
User Opening
Telco 1
User
56
User
55
User
54
User
53
LEFT RIGHT User
52
User
51
User
50
User
49
8 4 2 1 8 4 2 1
RIGHT DATA VALUES LEFT DATA VALUES ADDRESS 0816
User
64
User
63
User
62
User
61
LEFT RIGHT User
60
User
59
User
58
User
57
8 4 2 1
8 4 2 1
RIGHT DATA VALUES
LEFT DATA VALUE ADDRESS 0811
User Opening
Telco 1
User
24
User
23
User
22
User
21
LEFT RIGHT User
20
User
19
User
18
User
17
8 4 2 1
8 4 2 1
RIGHT DATA VALUES LEFT DATA VALUES ADDRESS 0812
User
32
User
31
User
30
User
29
LEFT RIGHT User
28
User
27
User
26
User
25
8 4 2 1 8 4 2 1
RIGHT DATA VALUES
LEFT DATA VALUES ADDRESS 0813
User Opening
Telco 1
User
40
User
39
User
38
User
37
LEFT RIGHT User
36
User
35
User
34
User
33
8 4 2 1
8 4 2 1
RIGHT DATA VALUES
LEFT DATA VALUE ADDRESS 0814
User
48
User
47
User
46
User
45
LEFT RIGHT User
44
User
43
User
42
User
41
8 4 2 1 8 4 2 1
RIGHT DATA VALUES
