NAPCO GEMINI GEM-P1664 User Manual

L NAPCO Security Systems
X GEM-P1664 Programming Instructions

Page 45
WI1423A 1/06
ZONE OPTIONS - ZONES 33 TO 48 (ADDRESS 1157-1272)
Direct Address Program Mode
ZONE OPTIONS ZONES 45-48
LEFT DATA VALUES ADDRESS
ZONES 41-44
RIGHT DATA VALUES
ZONES 37-40
LEFT DATA VALUES ADDRESS
ZONES 33-36
RIGHT DATA VALUES
ZN48 ZN47 ZN46 ZN45 L ADDR R ZN44 ZN43 ZN42 ZN41 ZN40 ZN39 ZN38 ZN37 L ADDR R ZN36 ZN35 ZN34 ZN33
50ms Loop Response (A) 8 4 2 1 8 4 2 1 8 4 2 1 8 4 2 1

Priority 8 4 2 1 1221 8 4 2 1 8 4 2 1 1157 8 4 2 1
Priority with Bypass 8 4 2 1 1222 8 4 2 1 8 4 2 1 1158 8 4 2 1
Auto-Bypass 8 4 2 1 1223 8 4 2 1 8 4 2 1 1159 8 4 2 1

Selective Bypass 8 4 2 1 1224 8 4 2 1 8 4 2 1 1160 8 4 2 1
Keyswitch Arming 8 4 2 1 1225 8 4 2 1 8 4 2 1 1161 8 4 2 1
Auto-Bypass Re-entry 8 4 2 1 1226 8 4 2 1 8 4 2 1 1162 8 4 2 1
Pre-Alarm Warning 8 4 2 1 1227 8 4 2 1 8 4 2 1 1163 8 4 2 1
Never Arm 8 4 2 1 1228 8 4 2 1 8 4 2 1 1164 8 4 2 1
24-Hour Zone 8 4 2 1 1229 8 4 2 1 8 4 2 1 1165 8 4 2 1

Alarm Output 8 4 2 1 1230 8 4 2 1 8 4 2 1 1166 8 4 2 1

Pulsed Alarm Output 8 4 2 1 1231 8 4 2 1 8 4 2 1 1167 8 4 2 1
PGM1 Output 8 4 2 1 1232 8 4 2 1 8 4 2 1 1168 8 4 2 1
PGM2 Output 8 4 2 1 1233 8 4 2 1 8 4 2 1 1169 8 4 2 1

Entry/Exit 1 8 4 2 1 1234 8 4 2 1 8 4 2 1 1170 8 4 2 1
Entry/Exit 2 8 4 2 1 1235 8 4 2 1 8 4 2 1 1171 8 4 2 1

Exit/Entry Follower 8 4 2 1 1236 8 4 2 1 8 4 2 1 1172 8 4 2 1

Auto Reset 8 4 2 1 1237 8 4 2 1 8 4 2 1 1173 8 4 2 1

Swinger Shutdown 8 4 2 1 1238 8 4 2 1 8 4 2 1 1174 8 4 2 1

Chime 8 4 2 1 1239 8 4 2 1 8 4 2 1 1175 8 4 2 1
Abort Delay 8 4 2 1 1240 8 4 2 1 8 4 2 1 1176 8 4 2 1
Power-up Delay 8 4 2 1 1241 8 4 2 1 8 4 2 1 1177 8 4 2 1
Day Zone Open 8 4 2 1 1242 8 4 2 1 8 4 2 1 1178 8 4 2 1
Day Zone Short 8 4 2 1 1243 8 4 2 1 8 4 2 1 1179 8 4 2 1
Alarm on Day Zone 8 4 2 1 1244 8 4 2 1 8 4 2 1 1180 8 4 2 1

Alarm Telco 1 8 4 2 1 1245 8 4 2 1 8 4 2 1 1181 8 4 2 1
Alarm Restore 1 8 4 2 1 1246 8 4 2 1 8 4 2 1 1182 8 4 2 1
Trouble Telco 1 8 4 2 1 1247 8 4 2 1 8 4 2 1 1183 8 4 2 1
Trouble Restore 1 8 4 2 1 1248 8 4 2 1 8 4 2 1 1184 8 4 2 1
Alarm Telco 3 8 4 2 1 1249 8 4 2 1 8 4 2 1 1185 8 4 2 1
Alarm Restore 3 8 4 2 1 1250 8 4 2 1 8 4 2 1 1186 8 4 2 1
Trouble Telco 3 8 4 2 1 1251 8 4 2 1 8 4 2 1 1187 8 4 2 1
Trouble Restore 3 8 4 2 1 1252 8 4 2 1 8 4 2 1 1188 8 4 2 1
No EOL Resistor 8 4 2 1 1253 8 4 2 1 8 4 2 1 1189 8 4 2 1
Trouble on Open 8 4 2 1 1254 8 4 2 1 8 4 2 1 1190 8 4 2 1
Trouble on Short 8 4 2 1 1255 8 4 2 1 8 4 2 1 1191 8 4 2 1

Zone Area 1 8 4 2 1 1256 8 4 2 1 8 4 2 1 1192 8 4 2 1
Zone Area 2 8 4 2 1 1257 8 4 2 1 8 4 2 1 1193 8 4 2 1
Interior (Stay) Bypass 8 4 2 1 1260 8 4 2 1 8 4 2 1 1196 8 4 2 1
Keypad Sounder on Alarm 8 4 2 1 1261 8 4 2 1 8 4 2 1 1197 8 4 2 1

2-Wire Smoke Detectors (B) 8 4 2 1 (•) 1262 (•) 8 4 2 1 8 4 2 1 1198 (•) 8 4 2 1

Fire (C) 8 4 2 1 1263 8 4 2 1 8 4 2 1 1199 8 4 2 1
Fire Alarm Verification (C) 8 4 2 1 1264 8 4 2 1 8 4 2 1 1200 8 4 2 1
RESERVED 8 4 2 1 (•) 1265 (•) 8 4 2 1 8 4 2 1 (•) 1201 (•) 8 4 2 1
Zone ANDing Group 1 8 4 2 1 1266 8 4 2 1 8 4 2 1 1202 8 4 2 1
Zone ANDing Group 2 8 4 2 1 1267 8 4 2 1 8 4 2 1 1203 8 4 2 1
Zone ANDing Group 3 8 4 2 1 1268 8 4 2 1 8 4 2 1 1204 8 4 2 1
Zone ANDing Group 4 8 4 2 1 1269 8 4 2 1 8 4 2 1 1205 8 4 2 1
Sensor Watch 8 4 2 1 1270 8 4 2 1 8 4 2 1 1206 8 4 2 1
RESERVED 8 4 2 1 1271 8 4 2 1 8 4 2 1 1207 8 4 2 1
Chime 2 8 4 2 1 1272 8 4 2 1 8 4 2 1 1208 8 4 2 1
 When the Easy Program Menu is used, these features are enabled by default.
 Enabled when "Enable SIA CP-01 Features?" is activated (Answer "Yes" in the EZ Programming Menu).
Zone Area 3 8 4 2 1 1258 8 4 2 1 8 4 2 1 1194 8 4 2 1
Zone Area 4 8 4 2 1 1259 8 4 2 1 8 4 2 1 1195 8 4 2 1
1. Select the desired zone option.
s
ZONE OPTIONS
50ms Loop Response
Priority
Priority with Bypass
Auto-Bypass
Selective Bypass
3. Search table below for data entry. 4. Enter data in address locations (left and right
digits). Press [Enter] or [ON/OFF] to save.
L ADDR R
blank (•) 0490 1
ADDRESS LOCATION
NOTE: Dark shaded boxes = option not available.
See Direct Address Programming Example page 22.
4821
DIGIT VALUE DATA ENTRY
Blank (
.
)
4821
1
4821
2
8124
3
4821
4
5
4821
4821
6
4821
7
421
DIGIT VALUE DATA ENTRY
8
421
9
421
0
124
B
4 21
C
D
4 21
4 2 1
E
4 2 1
F
8
8
8
8
8
8
8
8
For notes (A), (B) and (C), see next page.
2. Enable desired options for each zone
by drawing a circle  around its
corresponding binary data value. NOTE:
No circle = feature disabled.
