X GEM-P1664 Programming Instructions
L NAPCO Security Systems
Page 46
WI1423A 1/06
NOTES: (A) 50ms Loop Response only available for zones 1-8.
(B) 2-wire Smoke Detectors only available for zones 7 & 8, and Fire must also be selected.
(C) If Fire Alarm Verification is selected, then Fire must also be selected.
DEFAULTS: The zone options indicated are automatically set after exiting the Easy Menu Driven Mode.
--Priority, Selective Bypass, Alarm Output, Auto Reset, Swinger Shutdown and Zone Area 1 are enabled for the total number of zones entered in “# OF ZONES IN AREA1 ENTER # ZONES”.
--Alarm Telco 1 is enabled for the zone number(s) entered in “REPORT ALL ZONES TO CENTRAL ZONES? Y/N”.
--Entry/Exit 1 and Chime are enabled for the zone number(s) entered in “ENTRY/EXIT ZONES ENTER ZONE #”.
--Exit/Entry Follower and Interior Bypass are enabled for the zone number(s) entered in “INTERIOR ZONES ENTER ZONE #”.
--Pulse Alarm Output is enabled for the zone number(s) entered in “FIRE ZONES ENTER ZONE #” or “2-WIRE FIRE ZNS ENTER ZONE #”.
--Fire is enabled for the zone number(s) entered in “FIRE ZONES ENTER ZONE #”.
--2-Wire Smoke Detector is enabled for the zone number(s) entered in “2-WIRE FIRE ZNS ENTER ZONE #”.
ZONE OPTIONS - ZONES 49 TO 64 (ADDRESS 1285-1400)
Direct Address Program Mode
ZONE OPTIONS ZONES 61-64
LEFT DATA VALUES
ADDRESS
ZONES 57-60
RIGHT DATA VALUES
ZONES 53-56
LEFT DATA VALUES
ADDRESS
ZONES 49-52
RIGHT DATA VALUES
ZN64 ZN63 ZN62 ZN61 L ADDR R ZN60 ZN59 ZN58 ZN57 ZN56 ZN55 ZN54 ZN53 L ADDR R ZN52 ZN51 ZN50 ZN49
Priority 8 4 2 1 1349 8 4 2 1 8 4 2 1 1285 8 4 2 1
Priority with Bypass 8 4 2 1 1350 8 4 2 1 8 4 2 1 1286 8 4 2 1
Auto-Bypass 8 4 2 1 1351 8 4 2 1 8 4 2 1 1287 8 4 2 1
Selective Bypass 8 4 2 1 1352 8 4 2 1 8 4 2 1 1288 8 4 2 1
Keyswitch Arming 8 4 2 1 1353 8 4 2 1 8 4 2 1 1289 8 4 2 1
Auto-Bypass Re-entry 8 4 2 1 1354 8 4 2 1 8 4 2 1 1290 8 4 2 1
Pre-Alarm Warning 8 4 2 1 1355 8 4 2 1 8 4 2 1 1291 8 4 2 1
Never Arm 8 4 2 1 1356 8 4 2 1 8 4 2 1 1292 8 4 2 1
24-Hour Zone 8 4 2 1 1357 8 4 2 1 8 4 2 1 1293 8 4 2 1
Alarm Output 8 4 2 1 1358 8 4 2 1 8 4 2 1 1294 8 4 2 1
Pulsed Alarm Output 8 4 2 1 1359 8 4 2 1 8 4 2 1 1295 8 4 2 1
PGM1 Output 8 4 2 1 1360 8 4 2 1 8 4 2 1 1296 8 4 2 1
PGM2 Output 8 4 2 1 1361 8 4 2 1 8 4 2 1 1297 8 4 2 1
Entry/Exit 1 8 4 2 1 1362 8 4 2 1 8 4 2 1 1298 8 4 2 1
Entry/Exit 2 8 4 2 1 1363 8 4 2 1 8 4 2 1 1299 8 4 2 1
Exit/Entry Follower 8 4 2 1 1364 8 4 2 1 8 4 2 1 1300 8 4 2 1
Auto Reset 8 4 2 1 1365 8 4 2 1 8 4 2 1 1301 8 4 2 1
Swinger Shutdown 8 4 2 1 1366 8 4 2 1 8 4 2 1 1302 8 4 2 1
Chime 8 4 2 1 1367 8 4 2 1 8 4 2 1 1303 8 4 2 1
Abort Delay 8 4 2 1 1368 8 4 2 1 8 4 2 1 1304 8 4 2 1
Power-up Delay 8 4 2 1 1369 8 4 2 1 8 4 2 1 1305 8 4 2 1
Day Zone Open 8 4 2 1 1370 8 4 2 1 8 4 2 1 1306 8 4 2 1
Day Zone Short 8 4 2 1 1371 8 4 2 1 8 4 2 1 1307 8 4 2 1
Alarm on Day Zone 8 4 2 1 1372 8 4 2 1 8 4 2 1 1308 8 4 2 1
Alarm Telco 1 8 4 2 1 1373 8 4 2 1 8 4 2 1 1309 8 4 2 1
Alarm Restore 1 8 4 2 1 1374 8 4 2 1 8 4 2 1 1310 8 4 2 1
Trouble Telco 1 8 4 2 1 1375 8 4 2 1 8 4 2 1 1311 8 4 2 1
Trouble Restore 1 8 4 2 1 1376 8 4 2 1 8 4 2 1 1312 8 4 2 1
Alarm Telco 3 8 4 2 1 1377 8 4 2 1 8 4 2 1 1313 8 4 2 1
Alarm Restore 3 8 4 2 1 1378 8 4 2 1 8 4 2 1 1314 8 4 2 1
Trouble Telco 3 8 4 2 1 1379 8 4 2 1 8 4 2 1 1315 8 4 2 1
Trouble Restore 3 8 4 2 1 1380 8 4 2 1 8 4 2 1 1316 8 4 2 1
No EOL Resistor 8 4 2 1 1381 8 4 2 1 8 4 2 1 1317 8 4 2 1
Trouble on Open 8 4 2 1 1382 8 4 2 1 8 4 2 1 1318 8 4 2 1
Trouble on Short 8 4 2 1 1383 8 4 2 1 8 4 2 1 1319 8 4 2 1
Zone Area 1 8 4 2 1 1384 8 4 2 1 8 4 2 1 1320 8 4 2 1
Zone Area 2 8 4 2 1 1385 8 4 2 1 8 4 2 1 1321 8 4 2 1
Interior (Stay) Bypass 8 4 2 1 1388 8 4 2 1 8 4 2 1 1324 8 4 2 1
Keypad Sounder on Alarm 8 4 2 1 1389 8 4 2 1 8 4 2 1 1325 8 4 2 1
Fire (C) 8 4 2 1 1391 8 4 2 1 8 4 2 1 1327 8 4 2 1
Fire Alarm Verification (C) 8 4 2 1 1392 8 4 2 1 8 4 2 1 1328 8 4 2 1
Zone ANDing Group 1 8 4 2 1 1394 8 4 2 1 8 4 2 1 1330 8 4 2 1
Zone ANDing Group 2 8 4 2 1 1395 8 4 2 1 8 4 2 1 1331 8 4 2 1
Zone ANDing Group 3 8 4 2 1 1396 8 4 2 1 8 4 2 1 1332 8 4 2 1
Zone ANDing Group 4 8 4 2 1 1397 8 4 2 1 8 4 2 1 1333 8 4 2 1
Sensor Watch 8 4 2 1 1398 8 4 2 1 8 4 2 1 1334 8 4 2 1
RESERVED 8 4 2 1 1399 8 4 2 1 8 4 2 1 1335 8 4 2 1
Chime 2 8 4 2 1 1400 8 4 2 1 8 4 2 1 1336 8 4 2 1
When the Easy Program Menu is used, these features are enabled by default.
Enabled when "Enable SIA CP-01 Features?" is activated (Answer "Yes" in the EZ Programming Menu).
Zone Area 3 8 4 2 1 1386 8 4 2 1 8 4 2 1 1322 8 4 2 1
Zone Area 4 8 4 2 1 1387 8 4 2 1 8 4 2 1 1323 8 4 2 1
Step 1 Step 4 Step 4 Step 4 Step 4 Step 2 Step 2 Step 2 Step 2
See Steps listed at
bottom of page 44
To Next Page
