X GEM-P1664 Programming Instructions
L NAPCO Security Systems
Page 52
WI1423A 1/06
User Program Mode: Accessing Program Mode & User Codes
GEM-K2AS Keypad
USER01
(Direct Entry)
123___
Programming User Codes with GEM-K2AS Keypad
To Program User Codes
1. Enter 2-digit User Number
(01-64) directly using number
buttons (0-9).
2. Press the
R button.
3. Enter Code (1-6 digits) directly
using number buttons (0-9).
4. Press the
U button to save
each code.
NOTE: Press G 0 button to clear character at cursor.
To continue press P or Q button.
GEMINI
User01
A
R
M
E
D
COMPUTERIZED SECURITY SYSTEM
S
T
A
T
U
S
R 1 2 3
B 4 5 6
C 7 8 9 0
U
NEXT/YES
P
PRIOR/NO
Q
AREA
G
USER CODES
Programming User Codes with GEM-K3DGTL Keypad
To Program User Codes
1. Enter 2-digit User Number
(01-64) directly using number
buttons (0-9).
2. Press the
R button.
3. Enter Code (1-6 digits) directly
using number buttons (0-9).
4. Press the
U button to save
each code.
NOTE: Press G 0 button to clear character at cursor.
To continue press P or Q button.
GEMINI
A
R
M
E
D
COMPUTERIZED SECURITY SYSTEM
S
T
A
T
U
S
R 1 2 3
B 4 5 6
C 7 8 9 0
U
NEXT/YES
P
PRIOR/NO
Q
AREA
G
UP
INTERIOR
BYPASS
FIRE/TBL SYS TBL
CHIME
Flashing
GEM-K3DGTL Keypad
User Program Mode
User Number
User Code (Direct Entry)
UP
INTERIOR
BYPASS
FIRE/TBL SYS TBL
CHIME
0 I
INTERIOR
BYPASS
FIRE/TBL SYS TBL
CHIME
INTERIOR
BYPASS
FIRE/TBL SYS TBL CHIME
1
GEM-K4RF Keypad
User Program Mode
User Number
User Code (Direct Entry)
CHIME
BYPASS
FIRE
TROUBLE
UP
CHIME
BYPASS
FIRE
TROUBLE
01
CHIME
BYPASS
FIRE
TROUBLE
-
Programming User Codes with GEM-K4RF Keypad
To Program User Codes
1. Enter 2-digit User Number
(01-64) directly using number
buttons (0-9).
2. Press the
R button.
3. Enter Code (1-6 digits) directly
using number buttons (0-9).
4. Press the
U button to save
each code.
NOTE: Press G 0 button to clear character at cursor.
To continue press P or Q button.
Flashing
