NAPCO GEMINI GEM-P1664 User Manual

X GEM-P1664 Programming Instructions
L NAPCO Security Systems

Page 44
WI1423A 1/06
NOTES: (A) 50ms Loop Response only available for zones 1-8.
(B) 2-wire Smoke Detectors only available for zones 7 & 8, and Fire must also be selected.
(C) If Fire Alarm Verification is selected, then Fire must also be selected.
DEFAULTS: The zone options indicated are automatically set after exiting the Easy Menu Driven Mode.
--Priority, Selective Bypass, Alarm Output, Auto Reset, Swinger Shutdown and Zone Area 1 are enabled for the total number of zones entered in “# OF ZONES IN AREA1 ENTER # ZONES”.
--Alarm Telco 1 is enabled for the zone number(s) entered in “REPORT ALL ZONES TO CENTRAL ZONES? Y/N”.
--Entry/Exit 1 and Chime are enabled for the zone number(s) entered in “ENTRY/EXIT ZONES ENTER ZONE #”.
--Exit/Entry Follower and Interior Bypass are enabled for the zone number(s) entered in “INTERIOR ZONES ENTER ZONE #”.
--Pulse Alarm Output is enabled for the zone number(s) entered in “FIRE ZONES ENTER ZONE #” or “2-WIRE FIRE ZNS ENTER ZONE #”.
--Fire is enabled for the zone number(s) entered in “FIRE ZONES ENTER ZONE #”.
--2-Wire Smoke Detector is enabled for the zone number(s) entered in “2-WIRE FIRE ZNS ENTER ZONE #”.
ZONE OPTIONS - ZONES 17 TO 32 (ADDRESS 1029-1144)
Direct Address Program Mode
ZONE OPTIONS ZONES 29-32
LEFT DATA VALUES ADDRESS
ZONES 25-28
RIGHT DATA VALUES
ZONES 21-24
LEFT DATA VALUES ADDRESS
ZONES 17-20
RIGHT DATA VALUES
ZN32 ZN31 ZN30 ZN29 L ADDR R ZN28 ZN27 ZN26 ZN25 ZN24 ZN23 ZN22 ZN21 L ADDR R ZN20 ZN19 ZN18 ZN17

Priority 8 4 2 1 1093 8 4 2 1 8 4 2 1 1029 8 4 2 1
Priority with Bypass 8 4 2 1 1094 8 4 2 1 8 4 2 1 1030 8 4 2 1
Auto-Bypass 8 4 2 1 1095 8 4 2 1 8 4 2 1 1031 8 4 2 1

Selective Bypass 8 4 2 1 1096 8 4 2 1 8 4 2 1 1032 8 4 2 1
Keyswitch Arming 8 4 2 1 1097 8 4 2 1 8 4 2 1 1033 8 4 2 1
Auto-Bypass Re-entry 8 4 2 1 1098 8 4 2 1 8 4 2 1 1034 8 4 2 1
Pre-Alarm Warning 8 4 2 1 1099 8 4 2 1 8 4 2 1 1035 8 4 2 1
Never Arm 8 4 2 1 1100 8 4 2 1 8 4 2 1 1036 8 4 2 1
24-Hour Zone 8 4 2 1 1101 8 4 2 1 8 4 2 1 1037 8 4 2 1

Alarm Output 8 4 2 1 1102 8 4 2 1 8 4 2 1 1038 8 4 2 1

Pulsed Alarm Output 8 4 2 1 1103 8 4 2 1 8 4 2 1 1039 8 4 2 1
PGM1 Output 8 4 2 1 1104 8 4 2 1 8 4 2 1 1040 8 4 2 1
PGM2 Output 8 4 2 1 1105 8 4 2 1 8 4 2 1 1041 8 4 2 1

Entry/Exit 1 8 4 2 1 1106 8 4 2 1 8 4 2 1 1042 8 4 2 1
Entry/Exit 2 8 4 2 1 1107 8 4 2 1 8 4 2 1 1043 8 4 2 1

Exit/Entry Follower 8 4 2 1 1108 8 4 2 1 8 4 2 1 1044 8 4 2 1

Auto Reset 8 4 2 1 1109 8 4 2 1 8 4 2 1 1045 8 4 2 1

Swinger Shutdown 8 4 2 1 1110 8 4 2 1 8 4 2 1 1046 8 4 2 1

Chime 8 4 2 1 1111 8 4 2 1 8 4 2 1 1047 8 4 2 1
Abort Delay 8 4 2 1 1112 8 4 2 1 8 4 2 1 1048 8 4 2 1
Power-up Delay 8 4 2 1 1113 8 4 2 1 8 4 2 1 1049 8 4 2 1
Day Zone Open 8 4 2 1 1114 8 4 2 1 8 4 2 1 1050 8 4 2 1
Day Zone Short 8 4 2 1 1115 8 4 2 1 8 4 2 1 1051 8 4 2 1
Alarm on Day Zone 8 4 2 1 1116 8 4 2 1 8 4 2 1 1052 8 4 2 1

Alarm Telco 1 8 4 2 1 1117 8 4 2 1 8 4 2 1 1053 8 4 2 1
Alarm Restore 1 8 4 2 1 1118 8 4 2 1 8 4 2 1 1054 8 4 2 1
Trouble Telco 1 8 4 2 1 1119 8 4 2 1 8 4 2 1 1055 8 4 2 1
Trouble Restore 1 8 4 2 1 1120 8 4 2 1 8 4 2 1 1056 8 4 2 1
Alarm Telco 3 8 4 2 1 1121 8 4 2 1 8 4 2 1 1057 8 4 2 1
Alarm Restore 3 8 4 2 1 1122 8 4 2 1 8 4 2 1 1058 8 4 2 1
Trouble Telco 3 8 4 2 1 1123 8 4 2 1 8 4 2 1 1059 8 4 2 1
Trouble Restore 3 8 4 2 1 1124 8 4 2 1 8 4 2 1 1060 8 4 2 1
No EOL Resistor 8 4 2 1 1125 8 4 2 1 8 4 2 1 1061 8 4 2 1
Trouble on Open 8 4 2 1 1126 8 4 2 1 8 4 2 1 1062 8 4 2 1
Trouble on Short 8 4 2 1 1127 8 4 2 1 8 4 2 1 1063 8 4 2 1

Zone Area 1 8 4 2 1 1128 8 4 2 1 8 4 2 1 1064 8 4 2 1
Zone Area 2 8 4 2 1 1129 8 4 2 1 8 4 2 1 1065 8 4 2 1
Interior (Stay) Bypass 8 4 2 1 1132 8 4 2 1 8 4 2 1 1068 8 4 2 1
Keypad Sounder on Alarm 8 4 2 1 1133 8 4 2 1 8 4 2 1 1069 8 4 2 1

Fire (C) 8 4 2 1 1135 8 4 2 1 8 4 2 1 1071 8 4 2 1
Fire Alarm Verification (C) 8 4 2 1 1136 8 4 2 1 8 4 2 1 1072 8 4 2 1
Zone ANDing Group 1 8 4 2 1 1138 8 4 2 1 8 4 2 1 1074 8 4 2 1
Zone ANDing Group 2 8 4 2 1 1139 8 4 2 1 8 4 2 1 1075 8 4 2 1
Zone ANDing Group 3 8 4 2 1 1140 8 4 2 1 8 4 2 1 1076 8 4 2 1
Zone ANDing Group 4 8 4 2 1 1141 8 4 2 1 8 4 2 1 1077 8 4 2 1
Sensor Watch 8 4 2 1 1142 8 4 2 1 8 4 2 1 1078 8 4 2 1
RESERVED 8 4 2 1 1143 8 4 2 1 8 4 2 1 1079 8 4 2 1
Chime 2 8 4 2 1 1144 8 4 2 1 8 4 2 1 1080 8 4 2 1
 When the Easy Program Menu is used, these features are enabled by default.
 Enabled when "Enable SIA CP-01 Features?" is activated (Answer "Yes" in the EZ Programming Menu).
Zone Area 3 8 4 2 1 1130 8 4 2 1 8 4 2 1 1066 8 4 2 1
Zone Area 4 8 4 2 1 1131 8 4 2 1 8 4 2 1 1067 8 4 2 1
Step 1 Step 4 Step 4 Step 4 Step 4 Step 2 Step 2 Step 2 Step 2
See Steps listed at
bottom of page 44
