L NAPCO Security Systems
X GEM-P1664 Programming Instructions
Page 41
WI1423A 1/06
KEYPAD OPTIONS (ADDRESS 0723-0736 & 1055-1058)
Direct Address Program Mode
*Not for UL Installations.
KEYPAD OPTIONS: Select options for any of the 7 keypads.
1. Select the desired option entering the option number (1-8) for each digit.
2. Enter corresponding option number in address location.
NOTE: Dark shaded data value box shows option not available.
3. Press U or D to save.
[Default = blank (•) blank (•)] [Default = blank (•) blank (•)]
[Default = blank (•) blank (•)]
[Default = blank (•) blank (•)] [Default = blank (•) blank (•)] [Default = blank (•) blank (•)]
KEYPAD TYPE: Up to 7 keypads may be programmed, if they are connected.
NOTE: See Keypad Configuration Mode.
1. Select keypad type for each keypad from the tables shown.
2. Enter in corresponding right and left digit address locations above.
3. Press U or D to save.
KEYPAD OPTIONS (ADDRESS 1425-1431, 1440-1446)
RIGHT OPTION
blank (•) Disabled
1
Active
Keypad
KEYPAD
ASSIGNMENT
KEYPAD
NO.
KEYPAD OPTIONS
LEFT DATA VALUES (CIRCLE )
ADDRESS 1440-1446
KEYPAD OPTIONS
RIGHT DATA VALUES (CIRCLE )
RSRVD
PANEL
ACCESS
EASY
ARMING
AMBUSH LEFT ADDR RIGHT RSRVD
KEYPAD
PANIC
KEYPAD
AUX.
KEYPAD
FIRE
1 8 4 2 1
1440
8 4 2 1
2 8 4 2 1
1441
8 4 2 1
3 8 4 2 1
1442
8 4 2 1
4 8 4 2 1
1443
8 4 2 1
5 8 4 2 1
1444
8 4 2 1
6 8 4 2 1
1445
8 4 2 1
7 8 4 2 1
1446
8 4 2 1
[Default = blank (•) blank (•) from address 1440-1446] * NOTE: Keypad Aux. is not to be selected for UL Installations.
Keypad 5 Type
LEFT RIGHT
ADDRESS 1429
Keypad 2 Type
LEFT RIGHT
ADDRESS 1426
Keypad 6 Type
LEFT RIGHT
ADDRESS 1430
Keypad 3 Type
LEFT RIGHT
ADDRESS 1427
Keypad 4 Type
LEFT RIGHT
ADDRESS 1428
Keypad 7 Type
LEFT RIGHT
ADDRESS 1431
LEFT OPTION
blank
(•)
Burg Keypad
2
Wizard Keypad*
KEYPAD TYPE
[Default = blank (•) blank (•)] [Default = blank (•) blank (•)]
Keypad 1 Type
LEFT RIGHT
ADDRESS 1425
