SYSTEM OPTIONS (ADDRESS 2051-2054)
Direct Address Program Mode
[Default = blank (•) blank (•)]
LEFT DIGIT (SUM
OF DATA VALUES)
RIGHT DIGIT (SUM
OF DATA VALUES)
ADDRESS 2051
SYSTEM OPTIONS LEFT DATA
VALUES
(CIRCLE
RESERVED 1
RESERVED 2
Disable System Trouble
Audible Timeout
4
Enable "K Series" Style
Keypads
††
8
RIGHT DATA
VALUES
SYSTEM OPTIONS
1 Enable Keypad Set Time/
Date Message
2 Enable Cancel Report to
Telco 3
4 Disable [ON/OFF] as Easy
Exit
8 Enable GEM-PRINT
Module
[Default = blank (•) blank (•)]
LEFT DIGIT (SUM
OF DATA VALUES)
RIGHT DIGIT (SUM
OF DATA VALUES)
ADDRESS 2053
SYSTEM OPTIONS
LEFT DATA
VALUES
(CIRCLE
)
Digital Dialer Rpt Enter /
Exit Test Mode
1
Disable Call Waiting on
1st Attempt
2
Enable Keypad 1 Only
Programming
4
Enable CP-01 Egress
Tones Only
8
RIGHT DATA
VALUES
(CIRCLE
)
SYSTEM OPTIONS
1
Exit Time Restart
2
Sound Alarm On Exit Error
4
Rpt Exit Err/Recent Close
8
Enable CP-01 Limits
1. Select the desired option by circling the data values for each digit (left and right).
2. Add the data values (ex: F=15=(1+2+4+8) from the selected options. See page 23).
3. Enter in address location (left and right digits). NOTE: Dark shaded data value box shows option not available.
4. Press U or D to save.
[Default = blank (•) blank (•)]
LEFT DIGIT (SUM
OF DATA VALUES)
RIGHT DIGIT (SUM
OF DATA VALUES)
ADDRESS 2054
SYSTEM OPTIONS
LEFT DATA
VALUES
(CIRCLE
)
RESERVED 1
RESERVED 2
RESERVED 4
RESERVED 8
RIGHT DATA
VALUES
SYSTEM OPTIONS
1 Enable TCP/IP
Communications
2 RESERVED
4 RESERVED
8 RESERVED
[Default = blank (•) blank (•)]
LEFT DIGIT (SUM
OF DATA VALUES)
RIGHT DIGIT (SUM
OF DATA VALUES)
ADDRESS 2052
E15 LUG/
SYSTEM OPTIONS
LEFT DATA
VALUES
(CIRCLE
)
RESERVED 1
RESERVED
2
RESERVED
4
RESERVED 8
RIGHT DATA
VALUES
(CIRCLE
)
E15 LUG/
SYSTEM OPTIONS
1 RESERVED
2
RESERVED
4
Lug E15 Area 1 Armed
Away Only*
8
PGM on RF Transmitter
Tamper
*Note: (Address 2052) If this feature is not selected, the E15 Lug
will, by default, activate when the system is armed (all areas).
††
NOTE: This option is for reference only and cannot be changed.
