Napoleon WSX-EN Series User Manual

W415-2845 / B / 11.10.20
45
IOM
H20.1.1
The integrated furnace control has provisions to supply power and control an electronic air cleaner rated at
120VAC, 1.0 amp max. 120 volt power will be available at these terminals whenever the
circulating fan is operating in the heating or cooling fan modes.
H20.2
NOTE
All HUM and EAC terminals are 120V. Do not directly connect 24V equipment to these terminals.
The integrated furnace control has provisions to supply power and control a line voltage humidifi er or the
primary of a 120 / 24 volt humidifi er step down transformer, rated at 120VAC, 1.0 amp max.
16.0 OPTIONAL ACCESSORIES (FIELD SUPPLIED/
INSTALLED)
16.1 ELECTRONIC AIR CLEANER
16.2 POWER HUMIDIFIER
