51
7. Reattach the Thermal Transfer Ribbon as shown in the picture below and remove the slack of the
ribbon.
8. Close the Print /Encode Unit cover until it clicks.
9. Push RIBBON SET button.
10. Close the top cover, and then lock the top cover with the key.
“RIBBON SET” button
Turn unused side of the ribbon
counte
-clockwise to remove the slack
Thermal Transfer Ribbon
Unused side Used side
• Do not forget to push "RIBBON SET" button after installing a new ribbon. Otherwise, a print
failure will occur.
• Be sure to remove the slack of the Thermal Transfer Ribbon before closing the cover. The slack
will adversely affect the print quality.
Caution
To Next Page
