2-30 Installation Notes and Restrictions
LAN
The 7761 Motherboard provides 10/100/1000 Base T Ethernet support using Realtek
RTL8111F controller. The 7761 Motherboard supports Wake on LAN. The connector
features an integrated magnetic module and 2 LEDs. The LED on the left is yellow and
indicates Link/Activity at 1GBit speed when lit/flashing. The LED on the right is green
and indicates Link/Activity at 10/100Mbit speed when lit/flashing.
Pin SignalName
1 TD0+
2 TD0-
3 TD1+
4 TD1-
5 TD2+
6 TD2-
7 TD3+
8 TD3-
9 FRAME GND
10 FRAME GND
LAN Cable Kit
LANCable Kit
1432–C046–0030 POS; 10/100/1000 CAT 5EEthernet Cable (ANSIcompliantl; 8–wire
